Sliding door wall panels

PKD-100S (100 mm)

Door leaf constructed of steel sandwich panels with a core of 100mm polyurethane and an anodized aluminium framing profile. Top or bottom rolling in a standard galvanized rail system (no drop/lift rail system).

  • Good sealing. Door leaf sealed all round by means of double rubber profiles.
  • Optimum accessibility. The juxtaposition of several doors that slide past each other creates one large, movable wall facilitating fast and efficient loading and unloading.
  • Available as both top and bottom rolling doors. With bottom rolling doors, the bottom rail is embedded ensuring that it does not form an obstacle for construction traffic.
  • Available up to very large dimensions.
  • Available in kit form excluding door leaf panel. Easy to transport and favourably priced.
Aluminium profile.
All round by means of double rubber profiles.
Door leaf color
Standard colour RAL 9002 (light grey). Door leaf finished in colour to be specified at additional price.
Manually operated. Electrical operation at additional price.
Rail system
Rop or bottom rolling in galvanized finish.
R-value panels
Approx. 4,85 (m².K/W).
Pin lock on the outside to secure the door.
Door leaf constructed of sandwich panels, covered on both sides with 0.6mm sendzimir galvanized and coated steelplate.
Thickness door leaf
100 mm.
Exclusive, door leaf fully closed.,
Additional options
Cover / rain cap, door constructed in two parts (set) and bottom rail with gutter construction. Also available in kit form.
